Mounted Mobile Emergency Gas Turbine Generator Set — AGT4 4 MW High
The AGT4 delivers reliable 4 MW power output while maintaining the same installation footprint, upgraded with premium high-temperature hot-section materials to boost power density and cycle efficiency. Designed for continuous heavy-duty operation in large industrial CHP and combined cycle plants, the unit maintains stable performance across varying load profiles while capable of utilizing a wide range of low-calorific-value fuel gases to minimize energy expenditure.
Technical Specifications
| Item | Unit |
|---|
| Rated Net Output Power | 4000kw |
| Electrical Efficiency | 25.5% |
| Rated Output Voltage | 10.5kV |
| Operating Speed | 1500rpm |
| Power Factor (Lagging) | 0.8 |
| Rated Frequency | 50Hz |
| Exhaust Mass Flow | 21.7kg/s |
| Exhaust Gas Temperature | 516℃ |
| Acoustic Noise Level | 85 db(A) |
| Steam Output (1.0 MPa Saturated Steam) | 14t |
| Main Unit Overall Dimension | 8500×2678×3100mm |
| Main Unit Dry Weight | 32t |
Key Features & Benefits
Upgraded Hot-Section Materials Deliver Higher Power Within Identical Footprint
Advanced Thermodynamic Design Improves Combined Cycle Overall Efficiency
Elevated Steam Production Maximizes Thermal Revenue for CHP Operators
Intelligent Automated Controls Enable Stable Unsupervised Continuous Run Hours
Broad Fuel Flexibility Leverages Low-Calorific Industrial Waste Gas Resources
Target Industry Applications
Large-Scale Industrial Distributed Energy Systems
Petrochemical Combined Heat & Power Plants
Main Power Generation for Offshore Energy Platforms
Heavy Manufacturing Facility Permanent Backup Power
Combined Cycle Power Generation Facilities
Request a Custom Configuration
Our engineering team will work with you to configure the optimal gas generator set solution — fuel type, power output, enclosure, control system, and site requirements. Contact us with your specifications.
Contact Our Team →
